Taparia Flat Screw Driver With Insulated SD | PVC Insulated Blade, Magnetized Tip, IS 844-1979

Taparia Flat With Insulated SD is the insulated flat screwdriver range from Taparia’s screwdrivers section. Taparia states that the blade is made from high grade Silico–Manganese steel, the blade is scientifically heat treated for strength and wear resistance, the tip is precision-ground for firm slot grip, and the blade tip is magnetized. Taparia also states that, in electrician pattern, PVC insulation on the blade protects from electric shock and withstands a high voltage insulation test at 2000 V DC.

The handle is made from high grade special plastic for strength and durability, and the page lists the range under the screwdrivers-and-sets category with the official product title “Flat With Insulated SD.”

Core Technical Specifications

• Blade material: high grade Silico–Manganese steel.
• Blade treatment: scientifically heat treated for maximum strength and wear resistance.
• Tip: precision-ground for firm grip in the screw slot.
• Blade tip: magnetized.
• Handle material: high grade special plastic.
• Insulation note: in electrician pattern, PVC insulation on blade protects from electric shock and withstands a high voltage insulation test at 2000 V DC.
• Standard note: Taparia screwdrivers are generally conforming to I.S. 844-1979.


• Official Variant / Dimension Matrix from Taparia tools :




Product No.	A	B	ØC	T	Weight  (grams)
822I	200	125	3.5	0.5	30
842I	225	150	3.5	0.5	35
832I	275	200	3.5	0.5	40
823I	230	150	4	0.6	40
833I	280	200	4	0.6	40
934I	186	100	5	0.6	50
935I	211	125	5	0.6	55
936I	236	130	5	0.8	60
937I	286	200	5	0.8	70
938I	336	250	5	0.8	80
939I	386	300	5	0.8	90
824I	236	150	6	0.8	65
825I	286	200	6	0.6	77
826I	336	250	6	0.6	90
827I	305	200	8	0.1	145
8281	355	250	8	0.8	170
829I	405	300	8	0.1	180
928I	377	250	10	0.1	275
